| Fact Sheet | |
|---|---|
| Door type | Timber swing doors |
| Max seal drop | 20mm |
| Profile | 8x30mm, anodized aluminium |
| Max. length | 2000mm |
| Cut Back length | Variable. See descriptions |
| Positioning | Bottom of door |
| Drop actuator | Single sided |
| Adjustability | Max. protrusion 10mm |
| Movement | Parallel actuation & self-levelling |
| Seal colour | Grey |
| Manufacturing | 100% Made in Germany |
| Reliability | 5 Year manufacturer’s guarantee, tested to 1,000,000 cycles |
| Order codes & available lengths | |
|---|---|
| BAA1000/0820 | Schall-Ex® L-8/30 WS 820mm can be shortened to 648mm |
| BAA1000/0920 | Schall-Ex® L-8/30 WS 920mm can be shortened to 798mm |
| BAA1000/1070 | Schall-Ex® L-8/30 WS 1070mm can be shortened to 923mm |
| BAA1000/1220 | Schall-Ex® L-8/30 WS 1210mm can be shortened to 1048mm |
| BAA1000/1333 | Schall-Ex® L-8/30 WS 1333mm can be shortened to 1207mm |
| BAA1000/1500 | Schall-Ex® L-8/30 WS 1500mm can be shortened to 1457mm |
| BAA1000/1625 | Schall-Ex® L-8/30 WS 1625mm can be shortened to 1575mm |
| BAA1000/1833 | Schall-Ex® L-8/30 WS 1833mm can be shortened to 1616mm |
| BAA1000/2000 | Schall-Ex® L-8/30 WS 2000mm can be shortened to 1878mm |
